The JY-S5014B is an 860mm built-in gas hob with a black stainless steel finish, engineered for seamless integration into modern residential and light commercial kitchen spaces. This model caters to residential kitchen development projects, appliance distributors, and interior design firms sourcing standardized cooking appliances for commercial procurement needs. It is fitted with five independent burners and metal control knobs, with dual support for common gas types and optional safety components to align with varied project specifications and regional requirements.
This gas hob uses a 0.7mm thick black stainless steel panel, presenting a uniform dark appearance that coordinates with a wide range of contemporary kitchen design styles. The panel material supports routine cleaning with common kitchen cleaning agents and maintains its surface condition under regular daily use. The unit is equipped with cast iron pan supports, which hold cookware in a stable position during operation and accommodate cookware of different diameters and weights. Control knobs are constructed from metal, matching the overall build and aesthetic of the appliance.
The JY-S5014B is configured with five Chinese sabaf burners, covering a full range of heat output levels to support different cooking methods from simmering to high-heat stir-frying. The system includes one 3.3KW wok burner for high-heat cooking techniques, one 3.0KW rapid burner for general fast cooking, two 1.75KW semi-rapid burners for medium-heat preparation, and one 1.0KW auxiliary burner for low-heat simmering and warming. This range of heat settings allows the hob to adapt to varied daily cooking demands in both residential and light commercial kitchen environments.
This model adopts pulse ignition, with two power supply options available: battery-powered ignition and AC-powered ignition. Buyers may select the appropriate ignition type based on on-site installation conditions and existing kitchen wiring arrangements. A safety device is available as an optional add-on for projects that require additional flame-out protection features, allowing for full customization according to specific project standards and local regulatory requirements.
Item | Specification |
|---|---|
Model | JY-S5014B |
Product Type | 860mm built-in gas hob |
Panel Material | Black stainless steel |
Panel Thickness | 0.7mm |
Pan Support | Cast iron |
Burner Type | Chinese sabaf burner |
Heat Power (KW) | 3.3×3.0×1.75×1.75×1.0 Wok burner: 3.3KW×1 Rapid burner: 3.0KW×1 Semi-rapid burner: 1.75KW×2 Auxiliary burner: 1.0KW×1 |
Ignition Type | Pulse ignition with battery or AC |
Safety Device | Optional |
Gas Type | LPG/NG |
Product Size | 860×520×115 mm |
Carton Size | 900×550×145 mm |
The table below provides detailed dimensional data and container loading quantities, which can be referenced for logistics planning and bulk procurement budgeting:
Dimension(mm) | Loading quantity(pcs) | ||||
|---|---|---|---|---|---|
Unit | Built-in | Carton | 20GP | 40GP | 40HQ |
860X510X115 | 835X475 | 900X550X145 | 390 | 750 | 950 |
This 860mm built-in gas hob is suitable for upscale residential development and full-kitchen renovation projects. Its black stainless steel finish aligns with mainstream modern interior design trends, supporting uniform installation across multiple units in property development projects. The multi-burner configuration meets daily household cooking needs, making it a viable option for bulk procurement in real estate fit-out schemes.
For appliance distributors and regional supply operators, the JY-S5014B offers a standardized product with clear specifications and configurable options. The defined container loading quantities support inventory planning and bulk shipping arrangements, helping distributors optimize logistics costs and manage stock levels for regional market supply.
Interior design firms and commercial fit-out contractors can integrate this gas hob into custom kitchen design schemes for both residential and light commercial spaces. The uniform black stainless steel surface complements various cabinetry and countertop materials, delivering a cohesive visual effect for projects with consistent aesthetic requirements.
